Short Description:
Cutting tools in milling machines include holders and milling inserts. To cut metals, etc., by rotating, cutting tooth (inserts or heads) are attached to a main unit (holder), which is then attached to a machine tool, such as a machining centre with a tool holder.

Place Of Origin India

Return Returnable Product

Price: ₹ 6,300.00

Old price: ₹ 6,930.00

GST @18% Inclusive Price: 7434

This product has a minimum quantity of 5

Qty:

Product Specification

* INSERTS FOR WIDIA FACE MILLING CUTTER (WIDIA EQUIVALENT HNGJ0905ANSN GD-WP35CM)

* DIA 80MM WITH LEADANGLE 59 DEGREE

* INDEXES PER INS ERTS 12

* PITCH OF TOOL Z=8

* AXIAL DEPTH OF CUT AP1= 6MM ( MILLING OF STEEL/CAST IRON ) FOR KEKESIENUNIVERSAL MILLING MACHINE 100% C OMPATIBLE WITH ABOVE MENTIONED CUTTER DETAILS .

Application

Since milling inserts are detachable cutting tips, the milling machine does not include them. Since they are exchangeable and replaceable after usage, they are indexable. To cut or shape metals like steel, alloy, and cast iron, milling inserts are used with milling cutting tools. They are intended to prolong the life of your milling cutter by shielding it from harm brought on by intense heat and pressure.

Suggestion/Complaint

Insert for Face Milling Cutter-Dia 80MM with Lead Angle 59 Deg.
