Digital Multimeter-10A LCD Display with 3 and 1/2 Digit

Product Specification

• True RMS digital Industrial Multimeter:Equivalent model to the specification is Fluke 87-V Identify complex signal problems fast Supports accurate measurements on VFDs using a low-pass filter Captures intermittent as fast as 250 µS with Peak CaptureVoltage
• DCMaximum voltage : 1000 VAccuracy : ±(0.05% + 1)Maximum resolution : 10 µVVoltage ACMaximum voltage : 1000 VAccuracy : ±(0.7% + 2) True RMSAC bandwidth : 20 kHz with low pass filter; 3 dB @ 1 kHzMaximum resolution : 0.1 mVCurrent
• DCMaximum amps : 10 A (20 A for 30 seconds maximum)Amps accuracy : ±(0.2% + 2)Maximum resolution : 0.01 µACurrent ACMaximum amps : 10 A (20 A for 30 seconds maximum)Amps accuracy : ±(1.0% + 2) True RMSMaximum resolution : 0.1 µAResistanceMaximum resistance : 50 MΩAccuracy : ±(0.2% + 1)Maximum resolution : 0.1 ΩCapacitanceMaximum capacitance : 9,999
• µFAccuracy :±(1% + 2)Maximum resolution : 0.01 nFFrequencyMaximum frequency : 200 kHzAccuracy : ±(0.005% + 1)Maximum resolution : 0.01 HzDuty cycleMaximum duty cycle :99.9%Accuracy :±(0.2% per kHz + 0.1%)Maximum resolution : 0.1%
• Temperature measurement : –200.0 °C – 1090 °C –328.0 °F – 1994.0 °F, excluding probe80 BK temperature probe : –40.0 °C – 260 °C –40.0 °F – 500 °F, 2.2 °C or 2% whichever is greaterConductanceMaximum conductance : 60.00 nSAccuracy : ±(1.0% + 10)Maximum resolution : 0.01 nSDiodeRange : 3 VResolution : 1 mVAccuracy : ±(2% + 1)Duty cy

Application
